| Type (Cooling) |
|---|
| Indoor Unit |
| GK-2509YS1 |
| Performance Parameters | |
|---|---|
| Fan Speed | High/Low |
| Power | Single-phase, 50/60Hz 220-240/220V |
| Starting Current(A) | 0.43 |
| Weight(kg) | 10.5 |
| Air velocity Max. (m/sec) (50/60Hz)-High | 9.5/9.5 |
| Air velocity Max. (m/sec) (50/60Hz)-Low | 7/7 |
| Input (W) (50/60Hz)-High | 54-61/63 |
| Input (W) (50/60Hz)-Low | 52-59/54 |
| Air volume (m3/h) (50/60Hz)-High | 1210-1230/1170 |
| Air volume (m3/h) (50/60Hz)-Low | 980-1000/930 |
| Current(A)(50-60hz)-High | 0.25-0.26/0.29 |
| Current(A)(50-60hz)-Low | 0.24-0.25/0.25 |
| Compressor, Refrigerant & Ambient Operations | |
|---|---|
| Noise (dB) (50/60Hz) High In dB(A) | 43-44.5/43 |
| Noise (dB) (50/60Hz) Low In dB(A) | 38-41/35 |
| Type (Cooling) |
|---|
| Indoor Unit |
| GK-2512AS1 |
| Performance Parameters | |
|---|---|
| Fan Speed | High/Low |
| Power | Single-phase, 50/60Hz 220-240/220V |
| Starting Current(A) | 0.62 |
| Weight(kg) | 13.3 |
| Air velocity Max. (m/sec) (50/60Hz)-High | 9.5/9.5 |
| Air velocity Max. (m/sec) (50/60Hz)-Low | 7/7 |
| Input (W) (50/60Hz)-High | 76-83/84 |
| Input (W) (50/60Hz)-Low | 67-78/71 |
| Air volume (m3/h) (50/60Hz)-High | 1420-1440/1410 |
| Air volume (m3/h) (50/60Hz)-Low | 1150-1170/1090 |
| Current(A)(50-60hz)-High | 0.35-0.37/0.39 |
| Current(A)(50-60hz)-Low | 0.31-0.33/0.33 |
| Compressor, Refrigerant & Ambient Operations | |
|---|---|
| Noise (dB) (50/60Hz) High In dB(A) | 46-47/46.5 |
| Noise (dB) (50/60Hz) Low In dB(A) | 40.5-44/38 |
